Innolux 75 Inch LCD Panel with 3840x2160 Pixels UHD Resolution and 380 cd/m² Brightness for Interactive Whiteboard and TV LCD Screen

Model Number : V750DK1-KS5

Package : Original industrial packing

MOQ : 10pcs

Delivery Time : 4-5 working day

Color : 16.7M/1.07B

resolution : 3840*2160pixels UHD

Payment Terms : T/T,Western Union

working life : 30K hours

Price : Negotiation

Contrast ratio : 1400:1

Certification : Rohs,CE,FCC

brightnerss : 450CCD/M2

Supply Ability : 3000pcs per week

touch panel : without

Brand Name : LG

Quality : Brand new Original

Place of Origin : China

Connector : 97P

Packaging Details : Industrial packing

Contact Now

Innolux 75-Inch TV LCD Panel Model V750DK1-KS5
Note: This model has been discontinued
UHD 3840*2160 Pixels LCD Display with 380 cd/m² brightness, designed for interactive whiteboards and TV applications.
Innolux 75 Inch LCD Panel with 3840x2160 Pixels UHD Resolution and 380 cd/m² Brightness for Interactive Whiteboard and TV LCD Screen
Product Overview
The Innolux V750DK1-KS5 Rev.C1 is a 75-inch diagonal a-Si TFT-LCD display panel featuring an integral WLED backlight system with LED driver. This panel operates within a temperature range of 0~50°C and stores safely at -20~60°C. Originally mass produced in Q4 2014, this model is now discontinued.
Key Features
  • 120Hz refresh rate with 3D display capability
  • 10-bit color depth displaying 1.07 billion colors
  • Super MVA technology with normally black, transmissive display
  • WLED backlight with 30,000-hour lifespan
  • Matte surface with anti-glare and hard coating (3H)
  • V-by-One 8-lane interface with 56-pin connector
Technical Specifications
Manufacturer Innolux
Model Name V750DK1-KS5 Rev.C1
Display Size 75 inches
Panel Type a-Si TFT-LCD, LCM
Resolution 3840(RGB)*2160 (UHD), 16:9 aspect ratio
Brightness 380 cd/m² (Typical)
Contrast Ratio 4000:1 (Typical)
Viewing Angle 88/88/88/88 (CR≥20)
Response Time 6.5 ms (G to G, Typical)
Display Colors 1.07 billion, 88% NTSC
Display Area 1650.24(W) * 928.26(H) mm
Outline Size 1670.64(W) * 951.66(H) mm
Panel Weight 35.0 kg (Typical)
Interface V-by-One 8 lanes, 56 pins Connector
Input Voltage 12.0V (Typical)
Operating Temperature 0 ~ 50 °C
Storage Temperature -20 ~ 60 °C
Applications
  • TV Sets
  • Interactive Whiteboards
Important Notice: This model's production status is provided for reference only and should not be used as the basis for decision-making. For current production and specification details, please contact Innolux or their authorized distributors.
